Specifications
| Power supply Voltage | AC 220V±10% 2A 50Hz |
| Error of indication | ±1% |
| Indication variability | ＜1% |
| Force resolution | 0.1N |
| Force range | 5~500N |
| Specimen size | Width ≥ 25.4mm; Length ≥ 60mm |
| deformation error | ≤±1mm |
| Working Travel | 20~350mm |
| Pressurization speed | 48mm/min(1~500mm/min可设) |
| return speed | 5~500mm/min |
| Human Machine Interface | 4.3 "Color touchscreen |
| printout | modular integrated thermal printer |
| Communication interface | RS232 (std.)/USB (optional) |
| Operating Environment | Indoor temperature (20 +/- 10) ℃; Relative Humidity < 85% |
| Dimensions | 495*355*925mm |
| Weight | About 53kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28523/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
