Specifications
| Power supply Voltage | AC(100~240)V 5A 50/60Hz |
| Error of indication | ±1% |
| Indication variability | ≤1% |
| Force resolution | 1N |
| Force range | 50~10000N |
| Plate size | 500*500mm |
| Working Travel | 20~500mm |
| Pressurization speed | 10±1mm/min |
| return speed | 5~120mm/min |
| monitor | 4.3 "Color touchscreen |
| printout | modular integrated thermal printer |
| Communication interface | RS232 (std.)/USB (optional) |
| Operating Environment | Indoor temperature (20 +/- 10) ℃; Relative Humidity < 85% |
| Weight | About 166kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28524/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
