Specifications
| Power Supply | AC380V 50Hz |
| Test method | Face, corner, edge |
| drop height | 300~1500mm |
| test load | 0~100kg |
| Dimensions | 1700*1200*2400mm |
| Arm size | 220*280*8mm |
| Maximum size of specimen | 600*800*1000mm |
| Lifting Motor Power | 0.75KW |
| Reset Motor Power | 0.06KW |
| Weight | 750kg |
| Operating Environment | Temperature 5~ 35 ℃; Humidity < 85% R. H Voltage change ≤ +/- 10% |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28525/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
