Specifications
| Power supply Voltage | (100~240)VAC 2A 50/60Hz |
| Error of indication | ±1% |
| Indication variability | ＜1% |
| Resolution | 0.1N |
| Measurement range | (25~5000）N |
| deformation error | ±1mm |
| platen area | 300×300mm |
| Plate parallelism | ≤1mm |
| Working Travel | （5~350）mm |
| Specimen length | 300mm |
| Test speed of longitudinal compression | （10±2）mm/min |
| Test speed of transverse bending | （100±10）mm/min |
| Human Machine Interface | 4.3 "Color touchscreen |
| printout | modular integrated thermal printer |
| communication output | RS232 (std.)/USB (optional) |
| Operating Environment | Indoor temperature (20 +/- 10) ℃; Relative Humidity < 85%; |
| Dimensions | 535*425*805mm |
| Weight | About 81kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28530/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
