Specifications
| Power supply Voltage | (100~240)V AC 5A 50/60Hz |
| Error of indication | ±1% |
| Indication variability | ≤1% |
| Force resolution | 1N |
| Force range | 50~15000N |
| deformation error | ≤±1mm |
| Plate size | 1000*1000mm/800*800mm |
| Plate parallelism | ≤2mm |
| Working Travel | 20~1000mm |
| Pressurization speed | 10±1mm/min |
| return speed | 5~120mm/min |
| monitor | 4.3 "Color touchscreen |
| printout | modular integrated thermal printer |
| Communication interface | RS232 (std.)/USB (optional) |
| Operating Environment | Indoor temperature (20 +/- 10) ℃ Relative Humidity < 85% |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
