Specifications
| Pin stroke range | 0~2.5mm |
| Measurement range | 0~100HD |
| Measurement range | 20~90HD |
| Measurement error | ±1HD |
| Dimensions | 115*60*25mm |
| Weight | 0.16kg |
| Crimping head size | SR0.1mm |
| Pin end pressure | F = 445HD (mN), HD is the Shore D-type durometer reading |
Packing list
Hardness gauge x1, standard block x1, manual x1, warranty card x1, certificate x1
After-sales instructions
Warranty days: 365 days
1. Warranty: one year
2. Within 15 days after purchase, if there is a product quality problem in normal use and without damage to the appearance, the product of the same model and specification can be replaced with the invoice, valid warranty card and complete packaging;
3. There is no warranty for man-made failure or customer disassembly;
4. Products beyond the warranty period can be repaired by the original factory.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/2862/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
