Specifications
| maximum temperature | 1200℃ |
| Heating Elements | silicon carbide rod |
| Furnace material | aluminum silicate |
| Furnace Volume | 16L |
| Heating power | 10KW |
| Temperature control Accuracy | ±5%℃ |
| Temperature control instrument | Digital tube dual row PID |
| Thermocouple | Thermocouple K |
| Furnace size | 250*400*160mm |
| Power | AC380V/12A 50/60Hz |
| Dimensions | 600*910*635mm |
| Product Weight | 203kg |
| Heating method | Silicon carbide rod double-sided heating |
| Temperature Resolution | 1℃ |
| Room temperature to maximum temperature time | 70 |
| Heating method | staged warming |
| vent | Inner diameter 30mm * 1, rear (optional) |
| Exterior material | Cold rolled steel plate |
| Program Mode | optional |
| Temperature setting | Tap the four-button settings |
| Temperature representation | Measuring temperature display: 4-digit digital upper display; setting temperature display: 4-digit digital lower display |
| Timer | 0~9999min (with Timer waiting function) |
| Run function | Fixed value operation, Timer operation, automatic stop |
| Additional features | Deviation correction, menu button lock, power outage compensation, power outage memory |
| Packing size | 630*930*650mm |
| Gross Weight | 230kg |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28624/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
