BENTING CSRJX-2-13 tube furnace Resistance Furnace 1300 ℃

Shanghai BENTING CSRJX-2-13 tube furnace Resistance Furnace temperature control 1300 ℃, aluminum silicate furnace size φ 30 * 180mm, CSRJX-2-13 tube furnace Resistance Furnace using silicon carbon rod double-sided heating, Temperature Fluctuation of +/- 5% ℃.

Price: Please contact customer service

Model：

CSRJX-2-13

Certificate

BenTing

Manufacturer authorization

Contact

Details SPEC Con

BenTing CSRJX-2-13 Resistance furnaceSPEC

BenTing CSRJX-2-13 Resistance furnaceDetails

BenTing CSRJX-2-13 Resistance furnacePacking list

SKU: NB028628

maximum temperature: 1300℃

Heating workpiece: silicon carbide rod

Furnace material: aluminum silicate

Furnace Volume: Tube furnace

Heating power: 2KW

Temperature control Accuracy: ±5%℃

Temperature control instrument: Digital tube double row PID

Thermocouple: Thermocouple K

Furnace size: Φ30*180mm

Power supply Voltage: AC220V/9A 50/60Hz

Dimensions: 270*450*360mm

Weight: 20kg

Heating mode: Silicon carbide rod double-sided heating

Temperature Resolution: 1℃

Room temperature to maximum temperature time: 90

Heating mode: staged warming

vent: Inner diameter 30mm * 1, rear (optional)

Exterior material: Cold rolled steel plate

Program Mode: optional

Temperature setting method: Tap the four-button setting

Temperature representation: Measuring temperature display: 4-digit digital upper display; setting temperature display: 4-digit digital lower display

Timer: 0~9999min (with Timer and waiting function)

Operational Features: Fixed value operation, regular operation, automatic stop

Additional features: Deviation correction, menu button lock, power failure compensation, power failure memory

Packing size: 460*680*510mm

Gross Weight: 25kg

CSRJX-2-13

Resistance furnace

Features

●Integrated design, light and compact structure.

●Closed aluminum silicate furnace and lightweight insulation bricks to ensure the full use of heat.

●Parallel side-opening furnace door keeps the hot end away from the operation.

●The combination of PID microcomputer air Detector and precision sensor makes the temperature accurate.

●Dedicated function key to achieve temperature setting.

●Auxiliary menu, realize over-lift alarm, deviation correction, and menu locking.

●Optional exhaust device, conducive to ashing.

●10 and 12 series: nickel-chromium-aluminum alloy heating wire is embedded in the aluminum silicate furnace in a closed manner to reduce the corrosion of volatile gas to the heating wire.

●13 series: silicon carbon rod heating, rapid heating, high thermal efficiency.

security

● Over-lift alarm, menu lock

Comparison of parameters of SX series 1200 degree Celsius Resistance Furnace

Model		SRJX-4-13	SRJX-8-13	SRJX-2-13	SRJX-2.5-13
manner		Silicon carbon rods are heated on both sides
performance	Operating temperature range	1300℃
	Temperature resolution	1℃
	Temperature fluctuations	±5%℃
	Normal temperature to maximum temperature time	70	90	90	70
	Heating method	Phased warming
constitute	Exhaust outlets	Inner diameter 30mm*1, rear (optional)
	Furnace body	Aluminum silicate
	heater	Nickel-chromium-aluminum alloy wire
	Rated power	4kw	8kw	2kw	2.5kw
	Exterior	Cold-rolled steel plate
controller	Temperature control method	Digital tube double row PID
	Program mode	Matching
	Temperature setting method	Tap the four buttons to set it
	How the temperature is expressed	Measured temperature display: 4-digit digital upper display, set temperature display: 4-digit digital lower display
	timer	0~9999 minutes (with timer and other waiting functions)
	Run the function	Fixed-value operation, timed operation, automatic stop
	Additional features	Deviation correction, menu key locking, power failure compensation, power failure memory
	sensor	Type K
Safety devices		Overlift alarm
specification	Inner dimensions (WDH mm)	150250100	200500180	φ30*180	φ222180




	Dimensions (WDH mm)	510650485	570965600	270450360	270450360

	Outer packing size (WDH mm)	640850600	640930635	460680510	460680510
	Content volume	4L	18L	Tube furnaces	Tube furnaces
	Power supply (50/60Hz) rated current	AC220V/23A	AC380V/12A	AC220V/9A	AC220V/9A

	Net weight/gross weight kg	185/206	190/210	20/25	20/25
