Specifications
| maximum temperature | 1300℃ |
| Heating workpiece | silicon carbide rod |
| Furnace material | aluminum silicate |
| Furnace Volume | Tube furnace |
| Heating power | 2.5KW |
| Temperature control Accuracy | ±5%℃ |
| Temperature control instrument | Digital tube double row PID |
| Thermocouple | Thermocouple K |
| Furnace size | Φ22*180mm*2 |
| Power supply Voltage | AC220V/9A 50/60Hz |
| Dimensions | 270*450*360mm |
| Weight | 20kg |
| Heating mode | Silicon carbide rod double-sided heating |
| Temperature Resolution | 1℃ |
| Room temperature to maximum temperature time | 70 |
| Heating mode | staged warming |
| vent | Inner diameter 30mm * 1, rear (optional) |
| Exterior material | Cold rolled steel plate |
| Program Mode | optional |
| Temperature setting method | Tap the four-button setting |
| Temperature representation | Measuring temperature display: 4-digit digital upper display; setting temperature display: 4-digit digital lower display |
| Timer | 0~9999min (with Timer and waiting function) |
| Operational Features | Fixed value operation, regular operation, automatic stop |
| Additional features | Deviation correction, menu button lock, power failure compensation, power failure memory |
| Packing size | 460*680*510mm |
| Gross Weight | 25kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28629/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
