Specifications
| Temperature range | RT+5~80°C |
| Temperature Uniformity | ±1.0℃ |
| Temperature fluctuation | ±0.5℃ |
| Temperature Resolution | 0.1℃ |
| Liner material | stainless steel plate |
| Liner size | 400*360*450mm |
| Volume | 65L |
| Shelf (std.) | 2 pieces |
| Shelf (max.) | 9pcs |
| Temperature control mode | Liquid crystal dual row PID |
| Display | Measuring temperature display: liquid crystal upper display; setting temperature display: liquid crystal lower display |
| Timer | 0~9999 minutes (with Timer and waiting function) |
| Viewing Window | Yes. |
| Power | AC220V/2.3A 50/60Hz |
| Input power | 0.50kw |
| Enclosure Material | Cold rolled steel plate, surface resistance painting |
| Packing size | 550*550*840mm |
| Dimensions | 640*640*905mm |
| Net Weight | 44kg |
| Gross Weight | 49kg |
| way | Double duct forced convection |
| Thermal insulation material | Polyurethane |
| heater | Stainless steel heating tube |
| Exhaust port | Inner diameter 28mm * 1, top |
| Temperature setting | Tap the four-button settings |
| Run function | Fixed value operation, Timer operation, automatic stop |
| Program Mode | optional |
| Temperature transducer | Pt100 |
| Additional features | Deviation correction, menu button lock, power outage compensation, power outage memory, overlift preventer, speed regulating fan |
| Safety Devices | Overlift preventer |
| Shelf load bearing | 15kg |
| Shelf spacing | 35mm |
| Accessories | Shelf, RS485 interface, printer, recorder, external, communication, remote control, programmed temperature control, wireless SMS alarm, U disk data storage |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28632/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
