Specifications
| Convection mode | Double duct forced convection |
| Temperature range | RT+10~300℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Fluctuation | ±1 ℃ |
| Temperature Uniformity | ±2.5% |
| Chamber material | stainless steel plate |
| Enclosure Material | Cold rolled steel plate, surface resistance painting |
| Thermal Insulation | aluminum silicate fiber |
| Heating mode | Stainless steel heating pipe |
| Input Power | 5.0Kw |
| Exhaust Port | Should 28mm * 2, top |
| Thermostat | LCD dual row PID |
| Temperature setting method | Tap the four-button setting |
| Temperature representation | Measuring temperature display: liquid crystal upper display; setting temperature display: liquid crystal lower display |
| Timer | 0~9999Min (with Timer waiting) |
| Operational Features | Fixed value operation, regular operation, automatic stop |
| Program Mode | optional |
| Additional features | Deviation correction, menu button lock, power outage compensation, power outage memory, constant speed fan, overlift preventer |
| Temperature sensor | pt100 |
| Safety Devices | Over-rise alarm, over-rise preventer |
| Interior size | 660*760*1250mm |
| Dimensions | 900*960*1840mm |
| Packing size | 1051*1060*1949mm |
| Volume | 625L |
| Load per shelf | 15kg |
| Shelf (std.) | 7pcs |
| Shelf spacing | 150mm |
| Power supply Voltage | AC380V/7.6A |
| Net Weight | 113kg |
| Shelf (std.) | 2pcs |
| Shelf (std.) | 4pcs |
| Gross Weight | 137Kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28866/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
