Specifications
| Display | 4-Bit backlit LCD liquid crystal display |
| Measurement range | 1.0~300mm (determined by the probe, special requirements can be customized); 0.06-11 |
| Display Accuracy | 0.1mm |
| Material Code | 11 groups |
| Speed of sound | 500~9000m/s |
| Environmental temperature | 0-40℃ |
| Environmental humidity | ≤90％RH |
| Environmental requirements | The surrounding environment has no strong vibration, no strong magnetic field, no corrosion medium and serious dust. |
| Probe size | 5M-8 Sensors |
| Precision | ±(0.5%n+0.1) |
| Power Supply | 4 AA batteries |
| Volume | 140×60×24mm |
| Weight | 185g |
| Working Relative Humidity | ≤90％RH |
Packing list
Host X1, 5M < unk > 8 Sensors X1, Coupling agent X1, Instruction manual X1, calibrating block X1, portable case X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29017/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
