TAISITE 101-2A stainless steel Electric Forced Air Drying Oven 250 ℃/136L

TAISITE 101-2A stainless steel Electric Forced Air Drying Oven Interior size is 550 * 450 * 550mm, volume is 136L, laboratory blast oven, 101-2A Temperature range RT + 10~250 ℃, Temperature Fluctuation +/- 1.0 ℃, with timing operation, automatic stop function.
Model：
Certificate
Contact
Details SPEC CAT OI
Similar products

TaiSiTe 101-2A Electric Forced Air Drying OvenSPEC

TaiSiTe 101-2A Electric Forced Air Drying OvenDetails

TaiSiTe 101-2A Electric Forced Air Drying OvenPacking list

SKU
NB029025
Temperature range
RT+10~250℃
Temperature Fluctuation
±1.0℃
Temperature Resolution
0.1℃
Temperature Uniformity
±2.5％
Volume
136L
Interior size
550*450*550mm
Chamber material
stainless steel plate
Shelf (std.)
2pcs
Shelves (max)
17pcs
Load per shelf
15kg
Timer
0~9999Min (with Timer waiting)
Power supply Voltage
AC220V/9.1A 50/60Hz
Input Power
2.0Kw
Dimensions
852*618*780mm
Net Weight
53kg
Enclosure Material
Cold rolled steel plate, surface resistance painting
Thermal Insulation
aluminum silicate fiber
Heating mode
Stainless steel heating pipe
Exhaust Port
Inner diameter 28mm * 2, rear; top test hole
Thermostat
Digital tube double row PID
Temperature setting method
Tap the four-button setting
Temperature representation
Measuring temperature display: 4-digit digital upper display; setting temperature display: 4-digit digital lower display
Operational Features
Fixed value operation, regular operation, automatic stop
Program Mode
optional
Additional features
Deviation correction, menu button lock, power failure compensation, power failure memory
Temperature sensor
pt100
Packing size
975*695*910mm
Shelf spacing
25mm
Gross Weight
68Kg
Shelf (std.)
4pcs
Optional accessories
Shelf, RS485 interface, printer, recorder, external communication, remote control, programmed temperature control, wireless SMS alarm, U disk data storage
101-2A
Electric Forced Air Drying Oven
TAISITE 101-2A stainless steel Electric Forced Air Drying Oven 250 ℃/136L Picture

Features

  • The transverse air circulation structure is conducive to air mixing, high space utilization, and fast drying rate.

  • Convenient operation, fixed value operation, timed operation, automatic stop.

  • Dedicated function keys enable temperature setting.

  • Auxiliary menu, to achieve over-rise alarm, deviation correction, menu locking.

  • The forced fan heat dissipation and air intake structure makes the maximum working temperature of the fan < 50 °C, and the long-term longevity operation.

  • Security:Over-lift alarm, menu lock.

Advantages:

Figure 1:Multi-function control panel

Figure 2:Warming curve. Time is measured in minutes and temperature is measured in °C

Fig. 3: Exhaust holes: Multi-functional exhaust design


Parameter comparison

ModelRated powerContent volume
101-0A/101-0AB1.2KW43L
101-1A/101-1AB1.6KW71L
101-2A/101-2AB2.0KW136L
101-3A/101-3AB4KW225L
Other parameters
mannerSide air ducts force convection
Operating temperature rangeRT+10～250℃
Temperature resolution0.1℃
Temperature fluctuations±1.0℃
Temperature distribution accuracy±2.5％
Built-inB: Stainless steel plate None B: High-strength carbon steel plate
ExteriorCold-rolled steel plate, surface resistance * quality coating
Insulating materialsAluminum silicate fiber
Exhaust outletsInner diameter 28mm*2, rear, overhead test hole
Temperature control methodDigital tube double row PID
Temperature setting methodTap the four buttons to set it
Temperature representationMeasured temperature display: 4-digit digital upper display, set temperature display: 4-digit digital lower display
timer0~9999 minutes (with timed waiting function)
Run the functionFixed-value operation, timed operation, automatic stop
Program modeMatching
Additional featuresDeviation correction, menu key locking, power failure compensation, power failure memory
sensorpt100
Safety devicesOverlift alarm
clapboard2 pcs
Partition shelves4 pcs
Configurations can be addedPartition, RS485 interface, printer, Recorder, external communication, remote control, program thermometer, wireless SMS alarm, U disk data storage


FAQ
QI want to do a test on the GB/T1714 standard, is this electric air blowing dryer okay?
A Sure
