Specifications
| Temperature range | RT+10~300℃ |
| Temperature Fluctuation | ±1.0℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Uniformity | ±3.5％ |
| Volume | 65L |
| Interior size | 400*360*450mm |
| Chamber material | stainless steel plate |
| Shelf (std.) | 2pcs |
| Shelves (max) | 9pcs |
| Load per shelf | 15kg |
| Timer | 0~9999Min (with Timer waiting) |
| Power supply Voltage | AC220V/6.8A 50/60Hz |
| Input Power | 1.5Kw |
| Dimensions | 535*490*820mm |
| Net Weight | 43kg |
| Enclosure Material | Cold rolled steel plate, surface resistance painting |
| Thermal Insulation | aluminum silicate fiber |
| Heating mode | Nickel chromium alloy heating wire OCr27A17Mo2 |
| Exhaust Port | Should 28mm * 1, top |
| Thermostat | LCD dual row PID |
| Temperature setting method | Tap the four-button setting |
| Temperature representation | Measuring temperature display: liquid crystal upper display; setting temperature display: liquid crystal lower display |
| Operational Features | Fixed value operation, regular operation, automatic stop |
| Program Mode | optional |
| Additional features | Deviation correction, menu button lock, power outage compensation, power outage memory, over-rise preventer |
| Temperature sensor | pt100 |
| Packing size | 670*620*960mm |
| Shelf spacing | 35mm |
| Gross Weight | 49Kg |
| Safety Devices | Over-rise alarm, over-rise preventer |
| Convection mode | Natural convection |
| Shelf (std.) | 2pcs |
| Shelf | 4 pieces |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
