Specifications
| Temperature range | RT+5~65℃ |
| Temperature Fluctuation | ±0.5℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Uniformity | ±1℃ |
| Volume | 49L |
| Liner size | 400*350*450mm |
| Liner material | Mirror stainless steel |
| Shelf (standard) | 2pcs |
| Shelf (max.) | 7pcs |
| Load per shelf | 15kg |
| Timer Range | 0~9999min (or h) |
| Power supply Voltage | AC 220V/1.1A 50/60Hz |
| Input Power | 0.25kw |
| Dimension | 590*465*790mm |
| Net Weight | 33kg |
| Enclosure Material | Cold rolled steel plate, surface resistance painting |
| Thermal Insulation | Rubber sponge |
| heater | Heating tube |
| Exhaust Port | Inner diameter 28mm * 1, top |
| Temperature Control mode | PID |
| Temperature setting method | Tap the four-button setting |
| Temperature representation | Measuring temperature display: liquid crystal display, setting temperature display: liquid crystal display |
| Operational Features | Fixed value operation, regular operation, automatic stop |
| Program control function | optional |
| Additional features | Deviation correction, menu button lock, power failure memory |
| temperature sensor | pt100 |
| packing size | 750*625*936mm |
| Shelf spacing | 35mm |
| Gross Weight | 38kg |
| Safety Devices | Over-temperature alarm, over-rise preventer |
| Thermostatic mode | natural convection |
| Shelf (standard) | 2pcs |
| Shelf (standard) | 4pcs |
Packing list
Host X1, operation manual X1, certificate of conformity X1, warranty card X1
