Specifications
| Temperature range | RT+5~65℃ |
| Temperature Fluctuation | ±0.5℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Uniformity | ±1℃ |
| Volume | 124L |
| Liner size | 500*450*550mm |
| Liner material | Mirror stainless steel |
| Shelf (std.) | 2pcs |
| Shelf (max.) | 13pcs |
| Load per shelf | 15kg |
| Timer | 0 ~ 9999min （ h ） |
| Power | AC 220V/2.3A 50/60Hz |
| Input Power | 0.5kw |
| Dimensions | 650*575*815mm |
| Net Weight | 49kg |
| Enclosure Material | Cold rolled steel plate, surface resistance painting |
| Thermal Insulation | Rubber sponge |
| Heating device | Heating pipe |
| Exhaust Port | Inner diameter 28mm * 1, top |
| Temperature control mode | PID |
| Temperature setting | Tap the four-button setting |
| Temperature representation | Measuring temperature display: liquid crystal display, setting temperature display: liquid crystal display |
| Operational Features | Fixed value operation, regular operation, automatic stop |
| Program control function | optional |
| Additional features | Deviation correction, menu button lock, power failure memory |
| Temperature transducer | pt100 |
| Packing size | 850*720*1036mm |
| Shelf spacing | 35mm |
| Gross Weight | 53kg |
| Safety Devices | Over-temperature alarm, over-rise preventer |
| Thermostatic mode | Natural convection |
| Shelf (std.) | 2pcs |
| Shelf (std.) | 4pcs |
Packing list
Host X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29062/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
