Specifications
| Temperature range | Foster: RT + 5~ 80 ℃; drying: 80~250 ℃ |
| Temperature Fluctuation | A.±0.5℃；B.±1℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Uniformity | Foster +/- 1.0 ℃; drying +/- 2.5% |
| Volume | 30L |
| Interior size | 310*310*310mm |
| Chamber material | stainless steel plate |
| Shelf (std.) | 2pcs |
| Shelves (max) | 6pcs |
| Load per shelf | 15kg |
| Timer | 0~9999Min (with Timer waiting) |
| Power | AC220V/3.6A 50/60Hz |
| Input Power | Foster: 0.3Kw; drying: 0.8Kw |
| Dimensions | 445*440*690mm |
| Net Weight | 32kg |
| Enclosure Material | Cold rolled steel plate, surface resistance painting |
| Thermal insulation material | aluminum silicate fiber |
| Heating mode | Stainless steel heating tube |
| Exhaust port | Inner diameter 28mm * 1, top |
| thermostat | Liquid crystal dual row PID |
| Temperature setting | Tap the four-button settings |
| Temperature representation | Measuring temperature display: liquid crystal upper display; setting temperature display: liquid crystal lower display |
| Run function | Fixed value operation, Timer operation, automatic stop |
| Program Mode | optional |
| Additional features | Deviation correction, menu button lock, power outage compensation, power outage memory, speed regulating fan, overlift preventer |
| Temperature sensor | pt100 |
| Packing size | 560*560*830mm |
| Shelf spacing | 35mm |
| Gross Weight | 37Kg |
| Safety Devices | Overlift alarm, overlift preventer |
| Convection mode | Double duct forced convection |
| Shelf (std.) | 2pcs |
| Shelf (std.) | 4pcs |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29074/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
