Specifications
| Temperature range | RT+10~250°C |
| Temperature Fluctuation | ±1℃ |
| Temperature Resolution | 0.1℃ |
| Shelf temperature control uniformity | ±0.5 ℃ |
| Volume | 24L |
| Interior size | 300*300*270mm |
| Chamber material | stainless steel plate |
| Shelf (std.) | 2pcs |
| Shelves (max) | 2pcs |
| Load per shelf | 15kg |
| Timer | The fixed value runs for 10,000 hours; the program runs for 99 hours/step |
| Power | 220V 50Hz 50/60Hz |
| Input Power | 0.6Kw |
| Dimensions | 520*475*660mm |
| Net Weight | 40kg |
| Enclosure Material | Cold rolled steel plate, surface resistance painting |
| Thermal insulation material | aluminum silicate fiber |
| Heating mode | Freestanding Shelf Heating |
| Exhaust port | F10mm |
| thermostat | 5.0 inch LCD touch screen multi-segment PID full temperature segment program temperature control |
| Temperature setting | touch |
| Temperature representation | liquid crystal display |
| Run function | Fixed value operation, regular operation, automatic stop, program operation |
| Program Mode | 30 steps, 40 steps |
| Additional features | Deviation correction, outage compensation, real-time Linear dispersion recording |
| Temperature sensor | pt100 |
| Packing size | 679*609*767mm |
| Shelf spacing | 130mm |
| Gross Weight | 52Kg |
| Safety Devices | Self-diagnosis circuit, abnormal temperature sensor, Independent Overtemperature Protectioner |
| vacuum | <133Pa |
| Heating rate | From room temperature to maximum operating temperature ≤ 40min |
| Viewing Window | Bulletproof Tempered Glass |
| Vacuum Meter | Pointer |
| suction port | F10mm |
| Standard configuration | Independent Temperature Limiter, 2 Shelves |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
