TAISITE WPL-30BE Electric Thermostatic Incubator 80 ℃/30L
TAISITE WPL-30BE Electric Thermostatic Incubator adopts dual air duct forced convection, Temperature range RT + 5~ 80 ℃, fluctuation +/- 0.5 ℃, WPL-30BE inner size is 310 * 310 * 310mm, volume is 30L, 6 layers Shelf.
Model：
WPL-30BE
Similar products
TaiSiTe WPL-30BE Electric Thermostatic IncubatorSPEC
TaiSiTe WPL-30BE Electric Thermostatic IncubatorDetails
TaiSiTe WPL-30BE Electric Thermostatic IncubatorPacking list
- SKU
- NB029116
- Temperature range
- RT+5~80°C
- Temperature Fluctuation
- ±0.5℃
- Temperature Resolution
- 0.1℃
- Temperature Uniformity
- ±1.0℃
- Volume
- 30L
- Liner size
- 310*310*310mm
- Liner material
- stainless steel plate
- Shelf (std.)
- 2 pieces
- Shelf (max.)
- 6th floor
- Load per shelf
- 15kg
- Timer
- 0~9999 minutes (with Timer and waiting function)
- Power
- AC220V/0.7A 50/60Hz
- Input Power
- 0.15KW
- Dimensions
- 445*440*690mm
- Net Weight
- 32kg
- Enclosure Material
- Cold rolled steel plate, surface resistance painting
- Thermal insulation material
- Polyurethane
- heater
- Stainless steel heating tube
- Exhaust port
- Inner diameter 28mm * 1, top
- Temperature Control mode
- Liquid crystal dual row PID
- Temperature setting
- Tap the four-button settings
- Temperature representation
- Measuring temperature display: liquid crystal upper display; setting temperature display: liquid crystal lower display
- Run function
- Fixed value operation, Timer operation, automatic stop
- Program Mode
- optional
- Additional features
- Deviation correction, menu button lock, power outage compensation, power outage memory (overlift preventer), speed regulating fan
- Temperature sensor
- pt100
- Packing size
- 560*560*830mm
- Shelf spacing
- 35mm
- Gross Weight
- 37kg
- Safety Devices
- Overlift alarm (overlift preventer)
- way
- Double duct forced convection
- Shelf (std.)
- 2 pieces
- Shelf (std.)
- 4 pieces
WPL-30BE
Electric Thermostatic Incubator
Benefits:
High precision, high efficiency, safety, wide range.
Convenient operation, fixed value operation, timed operation, automatic stop.
Dedicated function keys enable temperature setting.
Auxiliary menu, to achieve over-rise alarm, deviation correction, menu locking.
Vertical double air duct air jacket, turbine centrifugal forced air supply, more uniform temperature.
Speed-controlled fans enable the use of lightweight, fine, powdery samples.
The forced fan dissipates heat and intakes the air structure, so that the maximum working temperature of the fan < 50°C
LCD multi-data full-screen operation display, power failure memory, power failure compensation
Overlift preventer
Detail design advantages
Figure 1: Heating curve: time unit: minutes, temperature unit: °C
Figure 2: Thickened safety door design: Thickened and heat-insulated safety door design reduces heat dissipation and makes the experiment more comfortable
Figure 3, multi-function control panel
WPL series
| Model | Rated power | Content volume |
| WPL-30BE | 0.15KW | 30L |
| WPL-45BE | 0.25KW | 45L |
| WPL-65BE | 0.5KW | 65L |
| WPL-125BE | 0.6KW | 125L |
| WPL-230BE | 0.7KW | 230L |
| Other parameters | ||
| manner | Dual air ducts force convection | |
| Operating temperature range | RT+5～80℃ | |
| Temperature resolution | 0.1℃ | |
| Temperature fluctuations | ±0.5 ℃ | |
| Temperature distribution accuracy | ±1.0℃ | |
| Built-in | Stainless steel plate | |
| Exterior | Cold-rolled steel plate, surface resistance * quality coating | |
| Insulating materials | polyurethane | |
| Temperature control method | LCD double-row PID | |
| Temperature setting method | Tap the four buttons to set it | |
| Temperature representation | Measured temperature display: LCD upper display, set temperature display: LCD lower display | |
| timer | 0~9999 minutes (with timed waiting function) | |
| Run the function | Fixed-value operation, timed operation, automatic stop | |
| Program mode | Matching | |
| Additional features | Deviation correction, menu button locking, power failure compensation, power failure memory (overlift preventer) | |
| clapboard | 2 pcs | |
| Partition shelves | 4 pcs | |
| Configurations can be added | Partition, RS485 interface, printer, Recorder, external communication, remote control, program thermometer, wireless SMS alarm, U disk data storage | |
