Specifications
| Temperature range | RT+5~80°C |
| Temperature Fluctuation | ±0.5℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Uniformity | ±1.0℃ |
| Volume | 45L |
| Liner size | 350*350*350mm |
| Liner material | stainless steel plate |
| Shelf (std.) | 2 pieces |
| Shelf (max.) | 7th floor |
| Load per shelf | 15kg |
| Timer | 0~9999 minutes (with Timer and waiting function) |
| Power | AC220V/1.1A 50/60Hz |
| Input Power | 0.25KW |
| Dimensions | 485*480*730mm |
| Net Weight | 37kg |
| Enclosure Material | Cold rolled steel plate, surface resistance painting |
| Thermal insulation material | Polyurethane |
| heater | Stainless steel heating tube |
| Exhaust port | Inner diameter 28mm * 1, top |
| Temperature Control mode | Liquid crystal dual row PID |
| Temperature setting | Tap the four-button settings |
| Temperature representation | Measuring temperature display: liquid crystal upper display; setting temperature display: liquid crystal lower display |
| Run function | Fixed value operation, Timer operation, automatic stop |
| Program Mode | optional |
| Additional features | Deviation correction, menu button lock, power outage compensation, power outage memory (overlift preventer), speed regulating fan |
| Temperature sensor | pt100 |
| Packing size | 600*600*857mm |
| Shelf spacing | 35mm |
| Gross Weight | 43kg |
| Safety Devices | Overlift alarm (overlift preventer) |
| way | Double duct forced convection |
| Shelf (std.) | 2 pieces |
| Shelf (std.) | 4 pieces |
Packing list
completeness-built unit X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29117/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
