Specifications
| Temperature range | RT+5~80℃ |
| Temperature Fluctuation | ±0.5℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Uniformity | ±1.0℃ |
| Volume | 230L |
| Liner size | 600*500*750mm |
| Liner material | stainless steel plate |
| Shelf (standard) | 2pcs |
| Shelf (max.) | The 17th floor. |
| Load per shelf | 15kg |
| Timer Range | 0~9999min (with Timer and waiting function) |
| Power supply Voltage | AC 220V/3.2A 50/60Hz |
| Input Power | 0.7KW |
| Dimension | 735*625*1220mm |
| Net Weight | 84kg |
| Enclosure Material | Cold rolled steel plate, surface resistance painting |
| Thermal Insulation | Polyurethane |
| heater | Nickel chromium alloy heating wire |
| Exhaust Port | Inner diameter 28mm * 2, top |
| Temperature Control mode | LCD dual row PID |
| Temperature setting method | Tap the four-button setting |
| Temperature representation | Measuring temperature display: liquid crystal upper display; setting temperature display: liquid crystal lower display |
| Operational Features | Fixed value operation, regular operation, automatic stop |
| Program control function | optional |
| Additional features | Deviation correction, menu button lock, power outage compensation, power outage memory (over-rise preventer), constant speed fan |
| temperature sensor | pt100 |
| packing size | 898*814*1347mm |
| Shelf spacing | 35mm |
| Gross Weight | 100kg |
| Safety Devices | Over-rise alarm (over-rise preventer) |
| Thermostatic mode | Double duct forced convection |
| Shelf (standard) | 2pcs |
| Shelf (standard) | 4pcs |
Packing list
Host X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29120/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
