Specifications
| number of holes | double row eight holes |
| way | Natural water convective heat transfer |
| Temperature range | RT+5~100℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Fluctuation | ±0.5℃ |
| Temperature Uniformity | ±1.0℃ |
| Interior | stainless steel plate |
| exterior | Cold rolled steel plate, surface resistant painting |
| heat insulation material | polyurethane |
| Heating device | Stainless steel heating pipe |
| Rated power | 2.0Kw |
| Temperature control mode | PID |
| Temperature setting method | Tap the button to set |
| Timer Range | 0~999Min (with Timer and waiting function) |
| Operational Features | Fixed value operation, regular operation, automatic stop |
| Program Mode | optional |
| Additional features | Deviation correction, menu button lock, power outage compensation, power outage memory |
| Sensors | CU50 |
| Safety Devices | Overrise alarm |
| Tank Size | 635*325*120mm |
| Dimension | 794*398*200mm |
| packing size | 863*477*235mm |
| Shelf load bearing | 5kg |
| Shelf layer | 1st floor |
| Power supply Voltage | AC220V/9.1A 50/60Hz rated current |
| Net Weight | 10KG |
| Gross Weight | 12KG |
Packing list
completeness-built unit X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
