Specifications
| type | Double-Sided, Single Workstation |
| Air flow | Vertical |
| Cleanliness class | Level 100 |
| collection efficiency | 0.5Um particles 99.9% or more |
| Average colony count | ≤ 0.5 pcs/dish (φ90mm culture dish) |
| Adjustable Wind Speed Range | Initial: 0.6; End: 0.2 (m/sec) |
| Adjustable Wind Speed Range | 0.2-0.6（m/sec) |
| Noise | ≤62dB(A) |
| Vibration Half-Amplitude | ≤3um |
| Illumrination degree | ≥300Lx |
| Working surface load bearing | 50kg |
| Interior | stainless steel plate |
| Exterior | Cold rolled steel plate, surface resistance painting |
| Work door | Tempered Glass |
| HEPA Filter | 820*600*50mm |
| Primary Filter | 520 * 490 * 5 each |
| Fluorescent lamp | 20W*① |
| UV Lamps | 20W*① |
| Fan | 300W |
| Level adjustment | Adjustment foot (40mm) |
| Controller | LED Controller |
| Fan location | overhead |
| Workspace size | 780*780*550mm |
| Dimensions | 935*780*1690mm |
| Packaging Dimensions | 1210*950*1755mm |
| Maximum Power | 0.4kw |
| Power | AC220V/1.8A 50/60Hz rated current |
| Net Weight | 142KG |
| Gross Weight | 220KG |
Packing list
completeness-built unit X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29136/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
