Specifications
| Temperature range | 0~65 ℃ (without humidification); 10~65 ℃ (with humidification) |
| Temperature Resolution | 0.1℃ |
| Temperature Fluctuation | High temperature: +/- 0.5 ℃ Low temperature: +/- 1 ℃ |
| Temperature Uniformity | ±1℃ |
| Input Power | 1.4KW |
| Power | AC220V/3.6A 50/60Hz |
| Liner size | 500*500*950mm |
| Dimensions | 640*710*1463mm |
| Shelf (std.) | 2 pieces |
| Volume | 250L |
| way | Forced convection |
| Liner material | Mirror stainless steel plate |
| Enclosure Material | Cold rolled steel plate, surface resistance painting |
| Thermal insulation material | Polyurethane |
| heater | Stainless steel heating tube |
| compressor | Air-cooled closed compressor |
| refrigerant | R134A |
| Defrost structure | manual |
| Humidity control mode | manual |
| Lead Hole | Inner diameter 52mm each |
| Controlled external Power | 1 external |
| Temperature Control mode | Single segment liquid crystal PID |
| Temperature setting | Touch key settings |
| Temperature representation | Measuring temperature display: liquid crystal upper display; setting temperature display: liquid crystal lower display |
| Timer | 0~99.9h |
| Run function | Fixed value operation, Timer operation, automatic stop, program operation |
| Program Mode | optional |
| Additional features | Deviation correction, menu button lock, power outage compensation, power outage memory |
| Temperature sensor | PT100 |
| Safety Devices | Over-rise alarm, overload protection |
| Shelf load bearing | 15kg |
| Shelf Layers | 12th floor |
| Shelf spacing | 60mm |
| Net Weight | 100kg |
| Gross Weight | 127kg |
| Shelf (std.) | 4 pieces |
| Packing size | 800*870*1580mm |
| UV sterilization | Yes. |
Packing list
completeness-built unit X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29161/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
