TAISITE GH6000 Incubator 252L
SETAISITE GH6000 Water-Jacketed Incubator uses water jacket heating and breeze domestic circulation. GH6000 is a 252L experimental bacterial incubator with over-rise alarm and low water level alarm function. Temperature range RT + 5~ 65 ℃.
Model：
GH6000
Similar products
TaiSiTe GH6000 Waterproof incubatorSPEC
TaiSiTe GH6000 Waterproof incubatorDetails
TaiSiTe GH6000 Waterproof incubatorPacking list
- SKU
- NB029167
- Temperature range
- RT+5~65℃
- Temperature resolution
- 0.1℃
- Temperature Fluctuation
- ±0.5℃
- Temperature Uniformity
- ±1.0℃
- Input Power
- 0.85Kw
- Power supply voltage
- AC 220V/3.9A 50/60Hz
- Liner size
- 600*600*700mm
- Dimension
- 720*720*990mm
- Shelf (standard)
- 2pcs
- volume
- 252L
- Thermostatic mode
- Water jacket heating + double air duct forced convection
- Liner material
- Mirror stainless steel plate
- Enclosure Material
- Cold rolled steel plate, surface resistance painting
- heat insulation material
- polyurethane
- heater
- Stainless steel heating tube
- Temperature Control mode
- Digital tube dual row PID
- Temperature setting method
- Tap the key settings
- Temperature representation
- Measuring temperature display: 3-digit digital upper display; setting temperature display: 3-digit digital lower display
- Timer Range
- 0~ 99.9h * 30 (with timing and waiting function)
- run function
- Fixed value operation, regular operation, automatic stop
- programmable function
- Standard
- Additional features
- Deviation correction, menu button lock, power outage compensation, power outage memory
- temperature sensor
- PT100
- safety device
- Over-rise alarm, low water level alarm
- Shelf load bearing
- 15kg
- Shelf (maximum)
- The 15th floor.
- Shelf spacing
- 40mm
- Net weight
- 70kg
- gross weight
- 88kg
- Shelf (standard)
- 4pcs
- packing size
- 927*876*1186mm
- exhaust port
- none
GH6000
Waterproof incubator
product advantages
The water jacket is heated, the breeze circulates inside, and the temperature is more uniform.
Convenient operation, fixed value operation, automatic stop.
Dedicated function keys for temperature setting.
Auxiliary menu to realize overheating alarm, deviation correction and menu lock.
Vertical double air duct air jacket, centrifugal forced air supply from the turbine, more uniform temperature.
Overheating alarm, menu lock, low water level alarm.
Advantages of detailed design
Figure 1. Temperature rise curve: time unit: minute, temperature unit: ℃.
Figure 2. Insulated glass design: Insulated glass design reduces heat dissipation and makes experiments more comfortable.
Figure 3. Multifunctional control panel.
GH series
| model | rated power | Internal volume |
| GH3000 | 0.45Kw | 41L |
| GH4500 | 0.65Kw | 111L |
| GH6000 | 0.85Kw | 252L |
| Other parameters | ||
| Way | Water jacket heating + double air duct forced convection | |
| Operating temperature range | RT+5~65℃ | |
| temperature resolution | 0.1°C | |
| temperature fluctuation | ±0.5℃ | |
| Temperature distribution accuracy | ±1.0℃ | |
| Interior | Mirror stainless steel plate | |
| Exterior | Cold-rolled steel sheet with chemical-resistant coating on the surface | |
| Insulation material | Polyurethane | |
| heater | stainless steel heating tube | |
| exhaust vent | none | |
| temperature control method | Digital tube double column PID | |
| temperature setting method | Touch four buttons to set | |
| Temperature representation | Measured temperature display: 3-digit upper display; set temperature display: 3-digit lower display | |
| timer | 0~99.9h (with timing waiting function) | |
| running function | Fixed value operation, timing operation, automatic stop | |
| program mode | Optional | |
| Additional features | Deviation correction, menu key lock, power failure compensation, power failure memory | |
| sensor | Pt100 | |
| safety devices | Overheating alarm, low water level alarm | |
| Partition | 2 pieces | |
| shelf | 4 pieces | |
| configuration can be added | Partition | |
