Specifications
| Measuring range | 0~6mm |
| resolution | 0.001mm |
| Indication of variability | ≤ 0.002mm or ≤ 0.5% |
| Measurement plane parallelism | ≤0.001mm |
| Measurement speed | 1mm/s~60mm/s (adjustable) |
| Regulator time | Adjustable from 0.1 to 5seconds |
| Number of continuous measurements | 1~ 99 times optional |
| Contact area | 200 ± 5mm ², chassis boss diameter (16 ± 0.15) mm |
| Contact Pressure | 100 ± 10kPa |
| Probe descent speed | 0.5 ~ 10mm / s, TAPPI (1.0 ± 0.3mm / s) () |
| Operating Environment | Temperature 10~35 ℃, Relative Humidity does not exceed 85% |
Packing list
completeness-built unit X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29190/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
