Specifications
| maximum temperature | 1200℃ |
| Temperature range | 300~1200℃ |
| Heating Elements | Nickel-chromium-aluminum alloy OCr27AL7Mo2 |
| Furnace material | polycrystalline mullite fiber |
| Furnace Volume | 2L |
| Heating power | 1.5KW |
| Temperature control Accuracy | ±1℃ |
| Heating time | ≤30min |
| Temperature control instrument | Single-stage temperature control digital display |
| Thermocouple | Thermocouple K |
| Furnace size | 200*120*80mm |
| Power | AC220V/7A 50/60Hz |
| Dimensions | 480*617*683mm |
| Product Weight | 40kg |
| Temperature Resolution | 1℃ |
| Exterior material | Cold rolled steel plate, surface resistance painting |
| vent | Outer diameter φ22, inner diameter φ18 |
| Temperature control instrument | Using microcomputer PID control |
| Setup method | Touch five button action, digital display settings |
| Display mode | Dual row LED digital display |
| Timer | 0~999.9h |
| Run function | Fixed value operation |
| Program Mode | Single stage operation |
| Additional features | Correction function, gating function |
| Safety Devices | Overcurrent leakage protection switch |
| Packing size | 650*760*790mm |
| Gross Weight | 45kg |
| Heating mode | Three-sided heating |
Packing list
completeness-built unit X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29200/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
