Specifications
| maximum temperature | 1200℃ |
| Temperature range | 300~1200℃ |
| Heating Elements | Nickel-chromium-aluminum alloy OCr27AL7Mo2 |
| Furnace material | polycrystalline mullite fiber |
| Furnace Volume | 16L |
| Heating power | 6KW |
| Temperature control Accuracy | ±1℃ |
| Heating time | ≤30min |
| Temperature control instrument | 7-Inch color touch screen program temperature control |
| Thermocouple | Thermocouple K |
| Furnace size | 400*250*160mm |
| Power | AC220V/27.3A 50/60Hz |
| Dimensions | 630*808*783mm |
| Product Weight | 80kg |
| Temperature Resolution | 1℃ |
| Exterior material | Cold rolled steel plate, surface resistance painting |
| vent | Outer diameter φ22, inner diameter φ18 |
| Temperature control instrument | Using microcomputer PID control |
| Setup method | Finger touch tap settings |
| Display mode | Color LCD display |
| Timer | 0~999.9h |
| Run function | Fixed value operation, program operation |
| Program Mode | The program runs 50 steps |
| Additional features | Correction Function, Gating Function, Real-time Linear dispersion recording, U disk data export |
| Safety Devices | Overcurrent leakage protection switch |
| Packing size | 790*960*900mm |
| Gross Weight | 86kg |
| Heating mode | Three-sided heating |
Packing list
completeness-built unit X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29212/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
