TAISITE MFLC-18/13D ceramic fiber muffle furnace 1300 ℃/18L

TAISITE MFLC-18/13D ceramic fiber muffle furnace is a single-stage experimental muffle furnace. MFLC-18/13D designed a furnace volume of 18L, the furnace material is polycrystalline mullite fiber, and the heating element is silicon carbide rod.
Model：
Certificate
Contact
Details SPEC CAT
Similar products

TaiSiTe MFLC-18/13D Ceramic muffle furnaceSPEC

TaiSiTe MFLC-18/13D Ceramic muffle furnaceDetails

TaiSiTe MFLC-18/13D Ceramic muffle furnacePacking list

SKU
NB029218
maximum temperature
1300℃
Temperature range
300~1300℃
Heating Elements
silicon carbide rod
Furnace material
Polycrystalline mullite fiber
Furnace Volume
18L
Heating power
8KW
Temperature control Accuracy
±1℃
Heating time
≤30min
Temperature control instrument
Single-segment temperature control digital display
Thermocouple
S-type Thermocouple
Furnace size
300*250*250mm
Power supply Voltage
AC380V/12.2A 50/60Hz
Dimension
620*749*963mm
Weight
80kg
Temperature Resolution
1℃
Exterior material
Cold rolled steel plate, surface resistance painting
vent
Outer diameter Should be 22, Inner diameter Should be 18
Temperature control instrument
Using microcomputer PID control
setting method
Tap five button action, digital display settings
Display mode
Dual LED digital display
Timer Range
0~999.9h
Operational Features
fixed value operation
Program Mode
single-stage operation
Additional features
Correction function, gating function
Safety Devices
Overcurrent leakage protection switch
packing size
795*885*1220mm
Gross Weight
95kg
MFLC-18/13D
Ceramic muffle furnace
TAISITE MFLC-18/13D ceramic fiber muffle furnace 1300 ℃/18L Picture

Benefits:

  • Integrated design, light and compact structure.

  • Vacuum-formed polycrystalline mullite fiber furnace chamber for effective heat insulation.

  • Parallel side-opening furnace doors keep the hot end away from the operation

  • Open the door and cut off the power, and the power recovery delay to ensure safety.

  • The double-case body is air-insulated and has a low surface temperature.

  • Exhaust device, which is conducive to ashing.

  • The high-precision microcomputer thermometer is well combined with the precision sensor, and the temperature is accurate.

  • Dedicated function keys enable temperature setting.

  • Auxiliary menu, realize overlift alarm, deviation correction, menu lock, overlift preventer.

  • Safety: over-lift alarm, menu lock, over-lift prevention, door opening and power failure, power recovery delay.

Comparison of MFLC ceramic fiber muffle furnace series parameters

ModelSingle-stage type(D)MFLC-3/13DMFLC-8/13DMFLC-12/13DMFLC-18/13DMFLC-27/13DMFLC-36/13D
Programmatic (P)MFLC-3/13PMFLC-8/13PMFLC-12/13PMFLC-18/13PMFLC-27/13PMFLC-36/13P
Touch Type(T)MFLC-3/13TMFLC-8/13TMFLC-12/13TMFLC-18/13TMFLC-27/13TMFLC-36/13T
PerformanceOperating temperature range300～1300℃
Control accuracy±1℃
Temperature resolution1℃
Heating time≤30min
compositionExteriorCold-rolled steel plate, surface resistant coating
Furnace bodyPolycrystalline mullite fibers
Furnace size200*150*10250*180*180300*200*200300*250*250300*300*300400*300*300
Exhaust holesThe outer diameter is φ22, and the inner diameter is φ18
heaterSilicon carbon rods
Heating power3KW4KW6KW8KW12KW14KW
ControlsThermostatsType D: Single-stage temperature control digital display P type: imported program temperature control digital display T type: 7-inch color touch screen program temperature control
Control modeUse a microcomputer PID control
How to set it upD/P type: touch five button action, digital display setting T-type: finger touch tap setting
How it is displayedD/P type: double line LED digital display T type: color LCD screen display
timing0~999.9 hours
Run the functionType D: Fixed-value operation P/T type: Fixed-value operation The program runs
Program modeType D: Single-stage operation Type P: Program runs 4 curves 40 steps Type T: Program runs 50 steps
sensorType S thermocouples
Ancillary featuresD/P type: Correction function Gating function Type T: Correction function Gating function Real-time curve recording U disk data export
Safety devicesOvercurrent leakage protection switch
SpecificationsDimensions (W*D*H mm)520*660*813550*698*893570*749*911620*749*963670*760*1031670*849*1033
Outer packing size (W*D*H mm)695*785*1070725*835*1150745*885*1170795*885*1220845*885*1290845*985*1290
Content volume3L8L12L18L27L36L
Net weight/gross weight kg40/5060/7070/8580/9590/105100/115
Power supply (50/60Hz) rated currentAC220V/13.6AAC220V/18.2AAC380V/9.1AAC380V/12.2AAC380V/18.2AAC380V/21.3A
