Specifications
| maximum temperature | 1300℃ |
| Temperature range | 300~1300℃ |
| Heating Elements | silicon carbide rod |
| Furnace material | Polycrystalline mullite fiber |
| Furnace Volume | 27L |
| Heating power | 12KW |
| Temperature control Accuracy | ±1℃ |
| Heating time | ≤30min |
| Temperature control instrument | Single-segment temperature control digital display |
| Thermocouple | S-type Thermocouple |
| Furnace size | 300*300*300mm |
| Power supply Voltage | AC380V/18.2A 50/60Hz |
| Dimension | 670*760*1031mm |
| Weight | 90kg |
| Temperature Resolution | 1℃ |
| Exterior material | Cold rolled steel plate, surface resistance painting |
| vent | Outer diameter Should be 22, Inner diameter Should be 18 |
| Temperature control instrument | Using microcomputer PID control |
| setting method | Tap five button action, digital display settings |
| Display mode | Dual LED digital display |
| Timer Range | 0~999.9h |
| Operational Features | fixed value operation |
| Program Mode | single-stage operation |
| Additional features | Correction function, gating function |
| Safety Devices | Overcurrent leakage protection switch |
| packing size | 845*885*1290mm |
| Gross Weight | 105kg |
Packing list
Host X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
