TAISITE MFLC-8/13P Experimental muffle furnace 1300 ℃/8L

TAISITE MFLC-8/13P experimental muffle furnace is a program temperature control ceramic fiber muffle furnace, the heating element is silicon carbide rod, Heating power 4KW, MFLC-8/13P adopts imported program temperature control digital display, the furnace size is 250 * 180 * 180mm, with gating and correction function.

Model：

MFLC-8/13P

Certificate

TaiSiTe

Manufacturer authorization

Contact

Details SPEC CAT

TaiSiTe MFLC-8/13P Ceramic muffle furnaceSPEC

TaiSiTe MFLC-8/13P Ceramic muffle furnaceDetails

TaiSiTe MFLC-8/13P Ceramic muffle furnacePacking list

SKU: NB029225

maximum temperature: 1300℃

Temperature range: 300~1300℃

Heating Elements: silicon carbide rod

Furnace material: Polycrystalline mullite fiber

Furnace Volume: 8L

Heating power: 4KW

Temperature control Accuracy: ±1℃

Heating time: ≤30min

Temperature control instrument: Imported program temperature control digital display

Thermocouple: S-type Thermocouple

Furnace size: 250*180*180mm

Power supply Voltage: AC220V/18.2A 50/60Hz

Dimension: 550*698*893mm

Weight: 60kg

Temperature Resolution: 1℃

Exterior material: Cold rolled steel plate, surface resistance painting

vent: Outer diameter Should be 22, Inner diameter Should be 18

Temperature control instrument: Using microcomputer PID control

setting method: Tap five button action, digital display settings

Display mode: Dual LED digital display

Timer Range: 0~999.9h

Operational Features: Fixed value operation, program operation

Program Mode: The program runs 4 Linear dispersion 40 steps

Additional features: Correction function, gating function

Safety Devices: Overcurrent leakage protection switch

packing size: 725*835*1150mm

Gross Weight: 70kg

MFLC-8/13P

Ceramic muffle furnace

Benefits:

Integrated design, light and compact structure.
Vacuum-formed polycrystalline mullite fiber furnace chamber for effective heat insulation.
Parallel side-opening furnace doors keep the hot end away from the operation
Open the door and cut off the power, and the power recovery delay to ensure safety.
The double-case body is air-insulated and has a low surface temperature.
Exhaust device, which is conducive to ashing.
The high-precision microcomputer thermometer is well combined with the precision sensor, and the temperature is accurate.
Dedicated function keys enable temperature setting.
Auxiliary menu, realize overlift alarm, deviation correction, menu lock, overlift preventer.
Safety: over-lift alarm, menu lock, over-lift prevention, door opening and power failure, power recovery delay.

Comparison of MFLC ceramic fiber muffle furnace series parameters

Model	Single-stage type(D)	MFLC-3/13D	MFLC-8/13D	MFLC-12/13D	MFLC-18/13D	MFLC-27/13D	MFLC-36/13D
	Programmatic (P)	MFLC-3/13P	MFLC-8/13P	MFLC-12/13P	MFLC-18/13P	MFLC-27/13P	MFLC-36/13P
	Touch Type(T)	MFLC-3/13T	MFLC-8/13T	MFLC-12/13T	MFLC-18/13T	MFLC-27/13T	MFLC-36/13T
Performance	Operating temperature range	300～1300℃
	Control accuracy	±1℃
	Temperature resolution	1℃
	Heating time	≤30min
composition	Exterior	Cold-rolled steel plate, surface resistant coating
	Furnace body	Polycrystalline mullite fibers
	Furnace size	20015010	250180180	300200200	300250250	300300300	400300300
	Exhaust holes	The outer diameter is φ22, and the inner diameter is φ18
	heater	Silicon carbon rods
	Heating power	3KW	4KW	6KW	8KW	12KW	14KW
Controls	Thermostats	Type D: Single-stage temperature control digital display P type: imported program temperature control digital display T type: 7-inch color touch screen program temperature control
	Control mode	Use a microcomputer PID control
	How to set it up	D/P type: touch five button action, digital display setting T-type: finger touch tap setting
	How it is displayed	D/P type: double line LED digital display T type: color LCD screen display
	timing	0~999.9 hours
	Run the function	Type D: Fixed-value operation P/T type: Fixed-value operation The program runs
	Program mode	Type D: Single-stage operation Type P: Program runs 4 curves 40 steps Type T: Program runs 50 steps
	sensor	Type S thermocouples
	Ancillary features	D/P type: Correction function Gating function Type T: Correction function Gating function Real-time curve recording U disk data export
	Safety devices	Overcurrent leakage protection switch
Specifications	Dimensions (WDH mm)	520660813	550698893	570749911	620749963	6707601031	6708491033
	Outer packing size (WDH mm)	6957851070	7258351150	7458851170	7958851220	8458851290	8459851290
	Content volume	3L	8L	12L	18L	27L	36L
	Net weight/gross weight kg	40/50	60/70	70/85	80/95	90/105	100/115
	Power supply (50/60Hz) rated current	AC220V/13.6A	AC220V/18.2A	AC380V/9.1A	AC380V/12.2A	AC380V/18.2A	AC380V/21.3A
