Specifications
| maximum temperature | 1400℃ |
| Temperature range | 300~1400℃ |
| Heating Elements | silicon carbide rod |
| Furnace material | polycrystalline mullite fiber |
| Furnace Volume | 3L |
| Heating power | 3KW |
| Temperature control Accuracy | ±1℃ |
| Heating time | ≤35min |
| Temperature control instrument | Imported program temperature control digital display |
| Thermocouple | S-type Thermocouple |
| Furnace size | 200*150*10mm |
| Power | AC220V/13.6A 50/60Hz |
| Dimensions | 520*660*813mm |
| Product Weight | 40kg |
| Temperature Resolution | 1℃ |
| Exterior material | Cold rolled steel plate, surface resistance painting |
| vent | Outer diameter φ22, inner diameter φ18 |
| Temperature control instrument | Using microcomputer PID control |
| Setup method | Touch five button action, digital display settings |
| Display mode | Dual row LED digital display |
| Timer | 0~999.9h |
| Run function | Fixed value operation, program operation |
| Program Mode | The program runs 4 Linear dispersion 40 steps |
| Additional features | Correction function, gating function |
| Safety Devices | Overcurrent leakage protection switch |
| Packing size | 695*785*1070mm |
| Gross Weight | 50kg |
Packing list
completeness-built unit X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29240/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
