Specifications
| maximum temperature | 1400℃ |
| Temperature range | 300~1400℃ |
| Heating Elements | silicon carbide rod |
| Furnace material | polycrystalline mullite fiber |
| Furnace Volume | 27L |
| Heating power | 12KW |
| Temperature control Accuracy | ±1℃ |
| Heating time | ≤35min |
| Temperature control instrument | 7-Inch color touch screen program temperature control |
| Thermocouple | S-type Thermocouple |
| Furnace size | 300*300*300mm |
| Power | AC380V/18.2A 50/60Hz |
| Dimensions | 670*760*1031mm |
| Product Weight | 90kg |
| Temperature Resolution | 1℃ |
| Exterior material | Cold rolled steel plate, surface resistance painting |
| vent | Outer diameter φ22, inner diameter φ18 |
| Temperature control instrument | Using microcomputer PID control |
| Setup method | Finger touch tap settings |
| Display mode | Color LCD display |
| Timer | 0~999.9h |
| Run function | Fixed value operation, program operation |
| Program Mode | The program runs 50 steps |
| Additional features | Correction Function, Gating Function, Real-time Linear dispersion recording, U disk data export |
| Safety Devices | Overcurrent leakage protection switch |
| Packing size | 845*885*1290mm |
| Gross Weight | 105kg |
Packing list
completeness-built unit X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29247/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
