Specifications
| maximum temperature | 1600℃ |
| Temperature range | 300~1600℃ |
| Heating Elements | Silicon molybdenum rod |
| Furnace material | polycrystalline mullite fiber |
| Furnace Volume | 16L |
| Heating power | 15KW |
| Temperature control Accuracy | ±1℃ |
| Heating time | ≤50min |
| Temperature control instrument | Imported program temperature control digital display |
| Thermocouple | S-type Thermocouple |
| Furnace size | 300*260*210mm |
| Power | AC380V 50Hz |
| Dimensions | 740*860*1182mm |
| Product Weight | 175kg |
| Temperature Resolution | 1℃ |
| Exterior material | Cold rolled steel plate, surface resistance painting |
| vent | Outer diameter φ22, inner diameter φ18 |
| Temperature control instrument | 7-Inch color touch screen program temperature control |
| Setup method | Finger touch tap settings |
| Display mode | Color LCD display |
| Timer | 0~999.9h |
| Run function | Fixed value operation, program operation |
| Program Mode | The program runs 50 steps |
| Additional features | Correction Function, Gating Function, Real-time Linear dispersion recording, U disk data export |
| Safety Devices | Overcurrent leakage protection switch |
| Packing size | 900*985*1390mm |
| Gross Weight | 195kg |
Packing list
completeness-built unit X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29269/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
