Specifications
| Lighting method | 45/0 (45 annular uniform illumination 0 ° reception); conforms to standard CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTM E1164, DIN5033 Teil7, GB 2893, GB/T 18833 |
| lighting source | Light spectrum LED light source, UV light source |
| Spectroscopic method | Concave grating spectroscopy |
| sensor | 256-Pixel dual array CMOS image sensor |
| Wavelength range | 400~700nm |
| Reflectance Measurement Range | 0~200% |
| Measurement caliber | Φ20mm（可定制Φ10mm、Φ4mm） |
| Non-contact measurement distance | 7.5mm |
| Sample height | 0~150mm |
| Distance adjustment method | Manual adjustment, automatic adjustment (can store test height) |
| Measurement mode | sample mode |
| Positioning method | Camera positioning |
| Color space | CIE LAB,XYZ,Yxy,LCh,CIE LUV,HunterLAB |
| Color difference formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00,ΔE（Hunter） |
| Chromaticity indicator | WI, YI, TI, homochromatic index MI, lightfastmess, color fastness, force, coverage |
| Viewing Angle | CIE 2 ° / 10 ° |
| Observation light source | D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/U30) |
| display mode | Light spectrum map/data, sample chromatic value, color difference value/map, chromaticity map, Color simulation, pass/fail results, display tolerance can be set |
| Measurement time | About 1.5s |
| Data storage | 40,000 sample mode + quality control mode; 10,000 continuous statistics mode |
| Spectral reflectance repeability | Standard deviation within 0.08% |
| Inter-station difference | ΔE * from < 0.2 |
| Measurement mode | Single measurement, average measurement (2~ 99 times) |
| Dimensions | 330*250*370mm |
| Weight | About 10Kg |
| Power | DC 24V, 3A power adapter Power |
| Lighting source life | 5 years more than 3 million measurements |
| Display | TFT true color 7inch, capacitive touch screen |
| Data Interface | USB/RS-232, Bluetooth ® 4.0 |
| Operating language | Simplified Chinese, English, Traditional Chinese |
| Operating conditions | 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m |
| Storage environment | -20~50 ℃, 0~85% RH (no condensation) |
| Chromatic value repeability | ΔE * ab within 0.03 |
Packing list
host X1, power adapter X1, data cable X1, correction box X1, manual X1, certificate X1, warranty card X1, correction box X1.
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
