Specifications
| Lighting method | D/8 ° (diffuse reflection uniform illumination 8 ° reception); in line with standard CIE No.15, GB/T 3978. |
| Integrating sphere size | F58mm |
| lighting source | Combination LED light source |
| sensor | Silicon photodiode |
| Wavelength range | 400~700nm |
| wavelength spacing | 10nm |
| Reflectance Measurement Range | 0~200% |
| Measurement caliber | F8mm |
| Color space | CIE LAB,XYZ,Yxy,LCh,CIE LUV |
| Color difference formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*cmc(l:c),CIE2000ΔE*00,ΔE(h) |
| Chromaticity indicator | WI, YI, TI, homochromatic index MI, lightfastmess, color fastness, force, coverage |
| Viewing Angle | CIE 2 ° / 10 ° |
| Observation light source | D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/U30) |
| display mode | Light spectrum graph/data, sample chromatic value, color difference value/graph, pass/fail result, Color bias, Color simulation, Color parameter setting (ΔE * 94 factor, ΔE * cmc factor, ΔE2000 factor), tolerance prompt, inverted display, time setting, language setting, factory reset |
| Measurement time | 1.5s |
| Spectral reflectance repeability | Standard deviation within 0.1% (400~700nm: within 0.2%) |
| Inter-station difference | ΔE * from < 0.2 |
| Dimensions | 90*77*230mm |
| Weight | 0.6kg |
| Battery life | Lithium-ion polymer lithium battery, 2800 times in 8 hours |
| Lighting source life | 5 years more than 1.60 million measurements |
| Display | TFT true color 3.5inch, capacitive touch screen |
| Data Interface | USB/RS232 |
| Data storage | More than 15,000 pieces (1000 pieces of master standard, 15,000 pieces of sample) |
| Operating conditions | 0~40℃（32~104°F） |
| Storage environment | -20~50℃ |
| Chromatic value repeability | ΔE * ab within 0.04 |
Packing list
host x1, power adapter x1, lithium battery x1, manual x1, SQC8 color management quality control analysis software x1, data cable x1, black and white correction cylinder x1, protective cover x1, wristband x1.
After-sales instructions
Warranty days: 1095 days
【Warranty Terms】
1. The manufacturer of this product promises a warranty period of 2 years.
2. Freight sharing limit during the warranty period: the sender pays.
3. Damage caused by improper use by customers is not covered by the warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/293/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
