Specifications
| Measurement geometry | 8°/d |
| Measurement caliber | Φ4mm |
| positioning method | Lighting positioning and cross positioning |
| Detection Sensors | Silicon photodiode array |
| Measurement face | Large area stable end face and small area measurement concave and convex end face |
| Color Space | CIE L*a*b*C*h* CIE L*a*b* CIE XYZ |
| color difference formula | ΔE*ab ΔL*a*b ΔE*C*h |
| Optional light source | D65 |
| light source device | LED blue excitation |
| Sexual repeability | ≤0.08ΔE*ab |
| Inter-instrument Agreement | ΔE*ab<0.5 |
| Power Supply | Rechargeable lithium-ion battery 3.7V@3200mAh |
| Charging time | About 8 hours = 100% battery |
| Measurable times after charging | 5000 measurements |
| Lighting source life | 5 years, more than 1.60 million times |
| Operating environment | -10~40 ℃, 0-85% Relative Humidity (non-condensing) |
| Storage environment | -20-50 ℃, 0~85% Relative Humidity (non-condensing) |
| Data Interface | USB port |
| PC software | CQCS3 high-end color quality management software |
| Printer (optional) | Micro thermal printer |
| storage | 100 standards 20,000 samples |
| Weight | 500g |
| Dimensions | 205*67*80mm |
Packing list
host X1, power adapter X1, data cable X1, correction box X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29300/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
