Specifications
| Measurement range | 0~24Mm (depending on the probe) |
| Low resolution | 0.1 µm (FH 4) / 0.2 µm (FH 10) |
| Repeatability | Better than +/- (1 µm + 0.5% read) |
| Measurement principle | principle of magnetostatics |
| recording rate | 1, 2, 5, 10, 20 read values per second (optional) |
| Calibration method | Factory settings, zero point calibrated, zero point + up to 4 point calibrated |
| unit system | Metric (µm, mm), Imperial (mils, inches) |
| statistical chart | Statistical charts, real-time trend charts |
| Interface | RS232 TTL + IrDA 1.0 + USB (via junction box) |
| Environmental temperature | - 10 ℃ to + 60 ℃ (Storage Temperature: - 20 ℃ to + 80 ℃) |
| Data storage | 240,000 pieces of data |
| Measurement mode | MAX Maximum, MIN Minimum, Offset, Mode |
| size | 153 mm x 89 mm x 32 mm |
| Weight | 310g |
| Power Supply | 4 x AA (LR06) batteries, or optional external Power Supply (90 - 240 V~/48 - 62 Hz) |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29302/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
