Specifications
| Measurement Range | 0.68~ 300mm (in steel), metric and imperial can be freely converted |
| probe diameter | Φ10mm |
| Lower limit of pipe measurement | Should 20mm * 3.0mm (5MHz probe); Should 15mm * 2.0mm (7MHz probe optional) |
| measurement error | +/- 0.04mm (< 10mm )； +/- 0.5% H + 0.01mm (> 10mm); H is the actual film thickness of the measured object |
| Display resolution | 0.01mm |
| unit system | Metric or imperial (optional) |
| Calibrated | Probe zero and two point calibrating function |
| measurement mode | There are two Operating Modes of thickness measurement: single-point thickness measurement and scanning thickness measurement |
| measurement speed | 4 times/sec for single point measurement, 10 times/sec for scanning mode |
| storage Capacity | 2000 Film thickness measurements can be stored |
| Sound speed range | 1000~9999m/s |
| Display | High contrast ratio segment LCD display, high luminance EL backlight |
| Data Interface | RS232 interface |
| Ambient Operating Temperature | -20~+50℃ |
| Working Relative Humidity | ≤90％ |
| Storage temperature | -30~+70℃ |
| Power Supply | 2 AA size alkaline batteries (No. 5) |
| Operating Time | More than 160 hours (when the backlight is not turned on) |
| Host size | 170×80×38mm |
| Weight | 255g |
