Specifications
| Display mode | digital explicit |
| Viscosity range | 6.076~1215 mPa·s |
| Rotor specification | 1''34'xR24 |
| Rotor speed | 0.5rpm、1rpm、2rpm、2.5rpm、4rpm、5rpm、10rpm、20rpm、50rpm、100rpm |
| Reproducibility | ±0.2%F.S |
| Measurement Accuracy | Within +/- 2.0% of full scale |
| Container size | 500ml |
| Power | Input Power Supply (host) DC12V 2A |
| peripheral interface | RS232C port |
| Instrument Weight | 6.0Kg (including base bracket) |
| Operating language | English |
| Environment Operating temperature | 0~40℃ |
| Environment Relative Humidity | Relative Humidity less than 90% (no condensation) |
| Full scale torque | 67.37μN·m |
| Base size | 300*300*450mm |
| current consumption | Below 50VA |
| Dedicated AC adapter | Input AC100~240V +/- 10%; Output DC12V |
| Materials in contact with liquid parts | Steel (SUS304, SUS303) |
| Display information | Viscosity measurement value (optional SI system, CGS system,% value) alarm, swirl/spin series, rotor number, swirl/spin speed and model display |
Packing list
Viscometer X1, certificate of conformity, warranty card, manual
