Specifications
| Capacity selection | 10kg |
| Force Precision | <±1% |
| force resolution | 1/500000 |
| force resolution | 1/10000 |
| Measurement range | 1~100%F.S |
| Precision indication | Better than +/- 1% |
| Test speed range | 0.5~500mm/min |
| effective travel | ≤ 650mm (without fixture) |
| Test space | Φ120mm |
| Force unit | Measurement units including SI units, users can also customize the required units |
| shutdown mode | Upper and lower limit safety settings, emergency stop button, program power and elongation settings, test piece damage sensing |
| test project | Can do tension, pressure and fatigue test (optional function) |
| Dimensions | 570*470*1200mm |
| Weight | Approx. 70kg |
| Power system | Stepping motor |
| Power supply Voltage | 1PH，AC220V，50Hz，10A或指定 |
