IWAVE WN700D Colorimeter measurement diameter 16mm
WN700D(Φ16mm)
IWAVE WN700D(Φ16mm) ColorimeterSPEC
IWAVE WN700D(Φ16mm) ColorimeterDetails
IWAVE WN700D(Φ16mm) ColorimeterPacking list
- SKU
- NB029455
- Lighting method
- CIE recommended lighting reception mode: d/8
- Color Space
- CIEL*a*b*,CIEL*C*h,Yxy
- Available Light Sources
- A,C,D50,D65,F2(CWF),F12(U30)
- Lighting source
- Combination LED
- Color difference formula
- CIEΔE*ab,CIEΔE*Ch
- Measurement caliber
- Φ16mm
- Sensors
- Linear array CMOS@256 pixels
- spectroscopy
- Diffraction grating
- Viewing Angle
- CIE 2°/10°
- Wavelength range
- 400~700nm
- wavelength interval
- 10nm
- Measurement time
- 2.5s
- Reflectance Measurement Range
- 0~200%
- Sexual repeability Accuracy
- Delta E < 0.07 (the average deviation of the whiteboard is taken from 30 measurements)
- Inter-instrument Agreement
- ΔE*ab<0.4
- Light source lifetime
- More than 50,000 hours
- Battery life
- More than 10000 measurements
- Display
- TFT True Color 2.8 inches @(16:9)
- data storage
- 100 master standards and 16,000 samples
- Operating temperature
- 0℃-40℃（32℉-104℉）
- Storage environment
- -20℃-50℃
- Humidity range
- Relative Humidity less than 85%, no condensation
- Weight
- 340g
- Dimensions
- 180*76*60mm
- Packing size
- 400*240*340mm
WN700D is a cost-effective Spectrophotometer designed by IWave, which adopts a professional electronic circuit system and perfect optical system, which has the advantages of high precision, good stability and strong anti-interference, and provides great reliability and convenience for color quality control in all walks of life.
Stability (ΔE<0.07)
The electronic circuit system and optical system of the entire instrument are intelligently monitored by independent new technology to ensure that the instrument is not subject to the external environment during each measurement, so as to achieve high stability (ΔE<0.07).
Difference between tables (ΔE<0.4)
The difference between the stages is the difference between the measurement data of each instrument.
In the process of product processing and production, the quality of each instrument is strictly controlled, and the quality inspection of each instrument is strictly controlled when the product is out of the warehouse, so as to ensure that the difference between each instrument is minimized, so as to create a reliable data-based customer communication environment for instrument users.
Professional power management system, stable and safe
WN700D spectroscopic Tester has three power supply modes: 3200mAH rechargeable lithium battery power supply, external 5V DC power supply, lithium battery and external 5V DC power supply at the same time;
After a lithium battery is charged, it can be measured more than 10,000 times, which is 8-10 times that of the same industry. The instrument is equipped with an overVoltage protection system, which activates the internal overVoltage system when the customer is connected to the wrong power supply, so as to protect the instrument from burning out.
Accurate spectral data and Lab values
The sampling high-precision spectral spectroscopic system and stable optical system can accurately separate different wavelengths of light waves, so as to obtain accurate spectral data and Lab values.
Averaging measurement function
The WN700D Spectrophotometer has an average measurement function, and the average number of measurements can be set from 1 to 99 times.
A wide range of light sources and color rendering parameters are measured
The instrument has six built-in light sources A, C, D50, D65, F2 (CWF) and F12 (U30) and three color rendering parameters (L*a*b*, L*C*h* and Yxy), which can meet the different color measurement needs of users.
In addition, two CIE observer angles (10° and 2°) and two chromatic aberration formulas (ΔE*ab and ΔE*CH) are available for the user to choose from.
Humanized design, small body, large use
The ergonomically designed body brings you a more comfortable measurement experience;
The 2.8-inch TFF color display and graphical user interface make it easier for you to operate;
Small body, big purpose. The fuselage is small in size, light in weight, and easy to carry;
Extended functionality, comprehensive and practical
WN700D Spectrophotometer can be connected with the computer software (optional), and the functions of the instrument can be expanded by using the computer software, which can realize the functions of data analysis, uploading, downloading, printing and manual input of LAB value, etc., and can also be connected with the micro printer (optional) to realize real-time printing of measurement data.
