Specifications
| Measurement principle | Magnetic induction + eddy current |
| Measuring range | 0 ~ 1250µm |
| margin of error | Zero point calibrated ± (1 + 3% H); two point calibrated ± [ (1%~ 3% H) ] H + 1.5 |
| Minimum measurement surface | 10*10mm |
| Minimum radius of curvature | Convex: 5mm; Concave: 5mm |
| thinnest matrix | 0.4mm |
| probe | belt line |
| Calibrated mode | Zero point calibrated, two point calibrated |
| Unit display | mm |
| Power | Two AA batteries |
| Standards | GB/T 4956─1985、GB/T 4957─1985、JB/T 8393─1996、JJG 889─95、JJG 818─93 |
| Language | English, Chinese |
| Display screen | LED liquid crystal display |
| Operating Temperature | 0-40℃ |
| Relative Humidity | ≤85% |
| Print function | without |
| Total Weight | 115G (including battery) |
| Complete-built unit size | 110*65*30mm |
Packing list
Host x1, iron substrate x1, non-iron substrate x1, calibration shim x1, AA battery x2, certificate x1, manual x1, Encasement box x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29461/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
