Specifications
| Rated Voltage | AC220V |
| Rated Frequency | 50/60 Hz |
| Input Power | 710W |
| output power | 430W |
| Rated torque | 12.1 N.cm |
| Operating Mode | S1 (continuous) |
| Operation control mode | Speed control turntable |
| Speed range | 13000~34000rpm |
| Speed regulation mode | 6th gear |
| Restart protection function | Yes |
| Approved torque | 12.0 N.cm |
| Work head material | SS 316L stainless steel |
| Adapt work head | 8G；10G ；12G ；18G；24G(选购) |
| Ambient Temperature | ≤40℃ |
| Allowable Relative Humidity | ≤80% |
| Dimensions | 215*310*720mm |
| Machine Weight | 8kg |
| Work head specification | 24G |
| Processing Capacity | 80~5000mL |
| Max. Processing Viscosity | 5000cp |
| Rotor maximum linear velocity | 18m/s |
| Maximum immersion liquid height | 165mm |
| Work head specification | 24mm |
| Working head length | 245mm |
| Operating temperature(MAX) | 120℃ |
| Work head material | SS 316L |
| Bearing material | PTFE |
| Minimum immersion liquid height | 50mm |
Packing list
host X1, base X1, column X1, pillar X1, support fixing frame X1, column wrench X1, 24G working head X1, disassembly tool X1, certificate of conformity, instruction manual
After-sales instructions
Warranty days: 365 days
【After-sales service】
1. The whole machine is guaranteed nationwide, and free maintenance is provided during the warranty period (except for vulnerable parts and man-made damage);
2. After-sales service is provided by the original factory;
3. Provide long-term technical support outside the warranty period.
