Specifications
| Rated Voltage | AC 220V |
| Rated Frequency | 50/60 Hz |
| Input Power | 160W |
| output power | 120W |
| Rated torque | 3.95 N.cm |
| Operating Mode | S1 (continuous) |
| Operation control mode | Speed control turntable |
| Speed range | 5000~35000rpm |
| Speed regulation mode | 6th gear |
| Approved torque | 3.0 N.cm |
| Work head material | SS 316L stainless steel |
| Ambient Temperature | ≤40℃ |
| Allowable Relative Humidity | ≤80% |
| Dimensions | 380*80*50mm |
| Machine Weight | 0.85kg |
| Work head specification | 6G/10G |
| Processing Capacity | 0.2~10mL(6G)，30~150mL(10G) |
| Max. Processing Viscosity | 200cp(6G)，100cp(10G) |
| Rotor maximum linear velocity | 8m/s（6G）；13m/s（10G） |
| Maximum immersion liquid height | 60mm（6G）；110mm（10G） |
| Work head specification | 6mm（6G）；10mm（10G） |
| Working head length | 125mm（6G）；178mm（10G） |
| Operating temperature(MAX) | 120℃ |
| Work head material | SS 316 |
| Bearing material | PTFE |
| Minimum immersion liquid height | 18mm（6G）；20mm（10G） |
Packing list
Homogenizer x1, 6G/10G working head, manual, warranty card
After-sales instructions
Warranty days: 365 days
【After-sales service】
1. The whole machine is guaranteed nationwide, and free maintenance is provided during the warranty period (except for vulnerable parts and man-made damage);
2. After-sales service is provided by the original factory;
3. Provide long-term technical support outside the warranty period.
