Specifications
| High Voltage manual pump Working pressure | 40Mpa |
| High Voltage manual pump plunger diameter | 12mm |
| High Voltage manual pump Mass | 4.5kg |
| Maximum pulling force of hydraulic cylinder | 10kN |
| Hydraulic cylinder center aperture | 18mm |
| Hydraulic cylinder piston stroke | 30mm |
| Hydraulic cylinder Mass | 1.8kg |
| Pressure gauge Measurement Range | 0~10KN |
| Pressure gauge Power | 1 9V battery |
| Pressure gauge Mass | 0.4kg |
| Resolution | 0.01KN |
| Pressure gauge indication error | ≤±2%F.S |
Packing list
Hollow hydraulic cylinder X1, manual pump (with Encasement box) X1, manual X1, warranty card X1, certificate X1
After-sales instructions
Warranty days: 1095 days
If the product quality is not caused by human beings, the manufacturer provides 3 years of free warranty service, except for accessories and consumables
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29540/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
