Specifications
| Measurement range | 1.0~152Mm (steel) |
| Probe Frequency | 5MHz |
| Probe model | PT-102-2000 Standard Probe |
| Probe diameter | Φ6.3mm |
| Probe line length | 1.2m |
| Display resolution | 0.01mm/0.001IN |
| Display | Large screen multi-function low temperature LCD display |
| backlight function | Off/normally open/automatic three Operating Modes, luminance has low/medium/high three, gear adjustable |
| scanning method | 100 point measurements per second to capture the thinnest values during scanning |
| Difference Mode | Displays the difference between the Measured value and the preset value. |
| Alarm function | If the Measured value is less than the minimum allowable value input by the user/higher than the maximum allowable value input by the user, the red light is on and there is an alarm sound prompt of BB, and the green light is on to indicate that the measurement is within the allowable range. |
| VX Speed of sound | Can measure the Speed of sound |
| unit system | mm/inch |
| Speed of sound | 305~18542m/s |
| zero | Manual or automatic zeroing |
| Gain range | 40~52dB (step spacing 3dB) |
| Pulse, repeability Frequency | 200Hz |
| Display refresh rate | 10Hz |
| keyboard | 9-Key waterproof, oil-resistant keyboard |
| Environmental temperature | -30℃~75℃ |
| Host size | 63.5*131.3*31.5mm |
| Weight | 312G (including battery) |
| Applicable standard | NIST & MIL-STD-4562A |
| Protection level | IP65 |
| Environmental temperature | -30~75℃ |
| Power Supply | 2 AA batteries, continuous use time up to 45 hours (the use time of different battery types will vary). When the battery power is insufficient, the monitor will display a low battery sign. Automatic shutdown function (it will automatically shut down after 5 minutes without any operation). USB interface Power Supply function |
| Data storage | The built-in 32M memory card can store 10,000 measurement data (divided into 40 storage files, each storage file can store 250 data). The storage file format is a universal .csv format, no special data communication software is required. |
Packing list
host X1, PT-102-2000 probe, coupling agent X1, No. 5 battery X2, factory certificate x1, Chinese and English instructions x1, instrument case x1.
After-sales instructions
Warranty days: 365 days
