Specifications
| Measurement range | 1.0~152Mm (penetration mode: 2.54~ 25.4mm) |
| Probe Frequency | 5MHz |
| Probe model | PT-102-2700 Standard Probe |
| Probe diameter | Φ6.3mm |
| Probe diameter | Φ9.53mm |
| Probe line length | 1.2m |
| Display resolution | 0.01mm |
| unit system | Imperial and metric systems |
| Speed of sound | 305~18542m/s |
| Pulse, repeability Frequency | 200Hz |
| Display refresh rate | 10Hz |
| Gain range | 40~52dB (step spacing 3dB) |
| zero | Manual or automatic zeroing |
| keyboard | 9-Key waterproof, oil-resistant keyboard |
| Host size | 63.5*131.3*31.5mm |
| Weight | 312G (including battery) |
| Shell material | Extruded aluminum shell, bottom cover, nickel plate aluminum plating, environmentally friendly packaging |
| Power Supply | 2 AA alkaline batteries |
| Environmental temperature | -30℃~75℃ |
| Environmental temperature | -30~75℃ |
Packing list
host X1, PT-102-2700 probe, coupling agent X1, No. 5 battery X2, factory certificate x1, Chinese and English instructions x1, instrument case x1.
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29548/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
