Specifications
| Measurement range | 1.0~152mm |
| Probe Frequency | 5MHz/chip |
| Probe style | Split probe |
| Probe diameter | Φ6.35mm |
| Probe line length | 4 foot cable |
| Display resolution | +/- 0.001 inches (0.01 mm) |
| unit system | Imperial and metric systems |
| Calibration method | Single and two point calibrated |
| Measurement mode | Pulse echo mode (PE), echo mode (EE) |
| Measurement speed | 309.88~ 18542 m/s |
| Storage Capacity | 4 GB internal SD card |
| Display | 1/8 inch VGA gray scale display (240 x 160 pixels); viewing area 62 x 45.7 mm (2.4 x 1.8 inches). EL backlight (on/off/auto/reverse). |
| Interface | USB-C 1.1 connectivity to PC and OSX |
| Power Supply | Line Power: USB-C to PC or power outlet; three AAA batteries |
| Host size | 63.5*165*31.5mm |
| Weight | 13.5 ounces (with battery) |
| keyboard | A membrane switch with 12 tactile keys |
| Calibrated Certificate | Factory calibrated: traceable to NIST & MIL STD- 45662A |
| Optional Sensors | Optional Sensor type with built-in dual path error correction for improved Linearity |
| alarm mode | Set high and low tolerances with buzzer and visual LED |
| scanning method | Acquires 250 readings per second and displays the smallest reading found when the transducer is removed |
| B-scan | Cross-sectional view. Velocity variable display (10 to 200 readings per second) |
| scan strip | Speed 10Hz. Visible in B-scan and large digital view |
| bar chart | Stability indicating measurement. Visible in B-scan and large digital view |
| pulse generator | 150V square wave pulser |
| receiver | Manual or AGC gain control with a range of 50dB, depending on the mode selected |
| Timer | Precise TCXO Timing with Single Pulse 100MHz 8-Bit Ultra-Low Power Digitizer |
Packing list
host X1, PT-102-2700 probe, coupling agent X1, No. 5 battery X2, factory certificate x1, Chinese and English instructions x1, instrument case x1.
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/29550/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
