Specifications
| Measurement range | 1.0~150mm |
| Probe style | PT-102-2700 Standard High Impedance Probe |
| Probe Frequency | 5.0MHz |
| Speed of sound | 1250~9999m/s |
| unit system | Metric or imperial system |
| Display resolution | 0.01mm |
| Probe diameter | Φ6.3mm |
| Probe diameter | Φ9.53mm |
| Alarm function | Upper and lower limit audio-visual alarm |
| Measurement mode | Pulse-echo mode, echo-echo mode (through coating) |
| Display | VGA gray display, 240x160 pixels. |
| Data storage | 12,000 storage pages (alphanumeric storage) |
| Interface | To RS232 interface, Windows PC interface software |
| Shell material | Extruded aluminum case, bottom cover is sealed with nickel-plated Aluminum Panel and sealing pad |
| Host size | 63.5*165*31.5mm |
| Weight | 385G (including battery) |
| Environmental temperature | -10~60℃ |
Packing list
host X1, PT-102-2700 probe, coupling agent X1, No. 5 battery X2, factory certificate x1, Chinese and English instructions x1, instrument case x1.
After-sales instructions
Warranty days: 365 days
